Nonlinear Dynamical Systems (NDS)
... is an umbrella term for the study of phenomena such as attractors, bifurcations, chaos, fractals, catastrophes, and self-organization, all of which describe systems as they change over time. There is a large variety of possible patterns and many interesting and useful interrelationships among these groups of constructs. Their origins are grounded most often in differential topology. SCTPLS is primarily concerned with how to apply them constructively to theoretical and practical problems in psychology, the biomedical sciences, organizational behavior and management economics, education, and elsewhere. Some of our members have been actively developing analytical methods, usually of a statistical nature, that can be used to test hypotheses with real data. Many of the ideas that we work with lend themselves to some precise yet provocative graphics.

Glossary of Nonlinear Terms
Alphabetically organized and compiled by Terry Marks-Tarlow, Keith Clayton, and Stephen Guastello.
More Resources for Basic Dynamics
Attractors and boundary conditions, an interactive animation by Mike Solomon
History of the BZ reaction produced by John A. Pojman.
Nonlinearity in Physics Tutorials by J. C. Sprott. Videotaped lectures explaining the basic principles of nonlinearity in physics.
 Attractors Attractors are the elements of nonlinear dynamics. An attractor is a piece of space. When an object enters, it does not exit unless a substantial force is applied to it. The simplest attractor is the fixed point. Some fixed points have spiral paths and some are more direct. Limit cycles and chaotic attractors are more complex in their movements over time, but they have the same level of structural stability. Structural stability means that all objects in the space are moving around according to the same rules. Oscillators, also known as limit cycles, are another type of attractor. Like the moon revolving around the early, once an object gets too close to the limit cycle it continues to orbit indefinitely or until a substantial force is applied. Oscillators can be pure and simple, or dampened to a fixed point by means of a control parameter. They can also be perturbed in the opposite direction to become aperiodic oscillators. There is a gradual transition from aperiodic produce a chaotic time series. A control parameter is similar to an independent variable in conventional research. Here it has the effect of altering the dynamics of the order parameter, which is similar in meaning to a dependent variable, except that it is not necessarily dependent. Order parameters within a system operate on their own intrinsic dynamics. Repellors are like attractors, but they work backwards. Objects that veer too close to them are pushed outward and can go anywhere, so long as they go away. This property of an indeterminable final outcome is what makes repellors unstable. Fixed points and oscillators, in contrast, are stable. Chaotic attractors (described below) are also stable in spite of their popular association with unpredictability. A saddle has mixed properties of an attractor and a repellor. Objects are drawn to it, but are pushed away once they arrive. An example is the perturbed pendulum shown at the right. A saddle is also unstable.
 Bifurcations Bifurcations are splits in a dynamic field that can occur when an attractor changes from one type to another, or where different dynamics are occurring in juxtaposing pieces of space. They can even produce the appearance and disappearance of new attractors. Bifurcations are patterns of instability that can be as simple as a critical point, curved trajectories, or more complex in structure. One or more control parameters is often involved to change the system from one regime to the next. The logistic map is one of the classic bifurcations. It was first introduced to solve a problem in population dynamics and has seen a variety of applications since then. Start with the function X2 = CX1 (1 - X1 ), with X1 and C in the range between 0 and 1. Calculate X2 and run it through the equation again to produce X3, then repeat a few more times. When C is small, the results stay within a steady state. When C becomes somewhat larger (let it become gradually larger than 1.0), X goes into oscillations. As C becomes larger still, the oscillations become more complex (period doubling). When C = 3.6, the output is chaotic. The chaotic regime is rendered as a jumble of interlaced trajectories. The vertical striations are intentional. There are brief episodes of calm within the overal turmoil. Bifurcations are often experienced as critical points or tipping points. They are a critical feature of catastrophe models.
More Resources for Chaos

Introduction to Chaos by Larry Liebovitch. This online presention provides a rapid coverage of the basis principles of Chaos Theory in an illuminating set of Powerpoint slides.

Chaos Demonstrations by Clauswitz.com. Video clips and FLASH APPS for the Lorenz Attractor, Brownian Motion, 3- Body Problem, Double Pendulum, Perturbed Pendulum, Logistic Map and Bifurcation, The Game of Life, Complex Adaptive Systems, and more!

Nonlinear Dynamics and Chaos: A Lab Demonstration Stephen H. Strogatz. Video demonstrates various chaotic systems and applications: double pendulum, water flows, aircraft wing design, electronic signal processing, and chaotic music.

Lorenz Attractor in 3D Images by Paul Bourke.

Simple model of the Lorenz Attractor. [video]. Watch the attractor evolve and develop over time.

Interactive Lorenz Attractor by Malin Christersson. See the full range of Lorenz Attractor dynamics in 3D with this interactive display. Change parameters, or grab the image

 Chaos Chaos is a particular nonlinear dynamic wherein seemingly random events are actually predictable from simple deterministic equations. Thus, a phenomenon that appears unpredictable in the short term may indeed be globally stable in the long term. It will exhibit clear boundaries and display sensitivity to initial conditions. Small differences in initial states eventually compound to produce markedly different end states later on in time. The latter property is also known as The Butterfly Effect and was first discovered by Edward Lorenz during an investigation of weather patterns. Chaos has some important connections and relationships to other dynamics, however, such as attractors, bifurcations, fractals, and self-organization. Not all examples of chaos are chaotic attractors, but several dozen structures for chaotic attractors are known, however. A chaotic attractor has the stability characteristic of the simpler attractors that were already described because all the points within the attractor and moving according to the same rule. The movements within the attractor basin are chaotic, and they contain both expanding and contracting movements. The paths of motion expend to the outer rim, then back again toward the center -- a pattern that can be observed in schools of fish or flocks of birds. The famous Lorenz attractor is shown at the right. A point moves along any of the trajectories on one lobe, but suddenly switches to the other lobe. The transition from one lobe to the other is as random as flipping a coin -- with the exception that it is a fully deterministic process instead. The Lorenz attractor is a system of three order paramters (movements along X, Y, and Z cartesean coordinates) and three control paramters. The control parameters goven the amount of spread between the lobes and their orientation along the cartesean axes. There are a few pathways by which a non-chaotic system can become chaotic. One is to induce bifurcations, an example of which was already described with the logistic map. Another pathway is to couple oscillators together. One oscillator acts as a control parameter that drives another oscillator. A third option is to create a field with multiple fixed point attractors close together and send an object into the field. The latter example actually captures the three body problem that Henri Poincare was studying in the 1890s when he first discovered what we call chaos today. The word chaos did not appear in the system science vocabulary until the 1970s, however.
More Resources for Fractals

Introduction to Fractals by Larry Liebovitch. Presentation provides a rapid coverage of the basic principles of Fractals and Self-similarity in an illuminating set of Powerpoint slides.

More About Fractals and Scaling by Larry Liebovitch. This online presentation covers some of the basic dynamical underpinnings of self-similarity.

The Mandelbrot Set by Malin Christersson. An iconic fractal that can be viewed at different levels of scale with this interactive display.

 Fractals A fractal is a geometric form in a non-integer number of dimensions, meaning that they do not fill up a whole 2-D or 3-D space. Fractals also have self-repeating structures. The same overall pattern is visible if we zoom in or out to different levels of scale. Their essential structures can be found in many examples in nature - the shapes of snowflakes, vegetable, lightning, neural structures. Why are they so visually engaging? J. C. Sprott's Fractal of the Day website, shown at the right, changes every day at midnight, US Central Time. It deploys two basic algorithms. One selects a fractal structure, and the second evaluates the design for its level of complexity and other aesthetic properties. Please visit the archives, which can be reached by tracing the link. Fractal analysis can also be used to assess and compare the complexity of visual images such as abstract art works. One of the more practical fractal functions is diffusion limited aggregation. This concept has been used to map the flow of contagious diseases across physical space. The pathogen spreads quickly down a central pathway, then fans out in multiple directions, then dissipates. The principle is more difficult to apply, however, when the pathogen spreads by means of a global transportation rather than simple physical proximity. There is an important connection between fractal structure and chaos: The basin, or outer boundary of a chaotic attractor is a fractal. This discovery quickly led to the calculation of a fractal dimensions in time series data, which were in turn used to characterize the complexity of a time series of biometric or psychological data. In principle, it should be possible to find a fractal structure at one level of scale that repeats at other (finer, broader) levels of scale. At one point in history, it was thought that the presence of a fractal structure in a time series was a clear indication that the time series was chaotic. This assumption turned out to be an oversimplification, however. A chaotic time series is composed of expanding and contracting segments. A much better "test for chaos" is the Lyapunov exponent associated with the time series. A Lyapunov exponent is actually a spectrum of values that is computed from the sequential differences numbers in a time series. A positive exponent indicates expansion, and a negative value indicates contraction toward a fixed point. A perfect 0.0 indicates a pure oscillator, which, in practice could be a little bit perturbed in the chaotic direction or dampened in the direction of a fixed point. The decision about the dynamic character of a time series is drawn from the largest Lyapunov exponent, which should be positive, while the sum of the other values should be negative. Conveniently, the largest Lyapunov exponent can be converted to a fractal dimension. Fractal dimensions between 0 and 1.0 indicate gravitation toward a fixed point. A value of 1.0 could indicate either a line or a perfect oscillator. Values between 1.0 and 2.0 are usually interpreted as the range of self-organized criticality, which reflects a balance between order and chaos. The connection between fractal structures, self-organization, and emergent events, which is developed later on in conjunction with self-organization. Fractal dimensions between 2.0 and 3.0 are chaotic, but with a bias toward relatively small fluctuations over time that are perforated by a few large ones. An example would be the flight path of a bird of prey that is checking out its terrain suddenly swoops down to the group to check out something delicious. Humans adopt a similar pattern in a grocery store, probably without thinking about it. The caveat here, however, is that grocery stores are much more organized than the critters running through the woods. The grocery store wants us to find what we are looking for; the critters do not want to be found by the hawk. Fractal dimensions greater than 3.0 are chaotic. One more caveat, however, is that there are many well-known chaotic attractors with fractal dimensions less than 3.0 and closer to 2.0. Not all examples of chaos are chaotic attractors. FRACTAL OF DAY LIVE FEED HERE Fractal of the Day A new fractal appears every night at midnight CST More
More Resources for Catastrophes

The Catastrophe Teacher by Lucien Dujardin. An Introduction to catastrophe theory for the experimentalist. Explores all seven models in the set of elementary catastrophe models.

Catastrophe Machine prepared by the American Mathermatical Society, based on Zeeman's original.

More Resources for Complex Systems

Complex Systems Demonstration Programs by Robert Goldstone. Predatory-prey relationships, Hebbian learning, and more.

NK Rugged Landscape [PDF] -- a tutorial by Kevin Dooley

Optimum Variability
A special issue of NDPLS (October, 2015) examines the relationship system complexity and the health, functionality, and adaptability of biomedical systems, individual well-being, and work group dynamics. See contents. Special order this issue.
 Entropy Entropy has been mentioned in conjunction with self- organizing processes, but without definition until now. The construct has undergone some important developments since it was introduced in the late 19th century. In its first incarnation it meant heat loss. This definition gave us the principle that systems will eventually dissipate heat and expire from "heat death." This generalization turned out to be incorrect for a century later. When statistical physics gelled in the early 20th century, entropy concerned the prediction of the location of molecules in motion under conditions of heat and pressure. It was not possible to target individual molecules, but it was possible to create metrics for the average motion of the molecules. This perspective eventually led to the third incarnation, which was Shannon's entropy and information functions in the late 1940s. The Shannon metrics are probably the most widely used versions of entropy today, either directly or as a basis for the derivation of further entropy metrics. Imagine that a system can take on any of a number of discrete states over time. It takes information to predict those states, and any variability for which information is not available to predict is considered entropy. Entropy and information add up to HMAX, maximum information, which occurs when the states of a system all have equal probabilities of occurrence. The nonlinear dynamical systems perspective on entropy, which is credited to Ilya Prigogine, however, is that entropy is generated by a system as it changes behavior over time, and thus it has become commonplace to treat information and entropy as the same thing and designate them with the same formula: Hs = [p log2(1/p)], where p is the probability associated with an observation belonging to one category in a set of categories; the summation is over the set of categories. Some authors, however, continue to distinguish the constructs of information and entropy as they were originally intended. Other measures of entropy have been developed for different types of NDS problems, however. A short list includes topological entropy, Kolmogorov-Sinai entropy, mutual entropy, approximate entropy, and Kullback-Leibler entropy and an associated statistic for the correspondence between a model and the data. To return to self-organizing phenomena, self-organization occurs when the new structure provides a reduction in entropy associated with the possible alternative states of the system. In other words the system picks a state that it likes best, so to speak. The construct of minimum entropy, introduced by S. Lee Hong, or free energy, introduced by Karl Friston, reflect a system's proclivity to adopt a neurological, cognitive, or behavioral strategy that minimizes the number of degrees of freedom required to make a maximally adaptive response. A related principle is the performance-variability paradox. There is a tendency to think of skilled performance (sports, music, carpentry) as actions produced exactly the same way each time they are produced. There are small amounts of variability, nonetheless, that arise from the numerous neurological and cognitive degrees of freedom that go into producing the action. You can prove the point to yourself by signing your name six times on a piece of paper. Is each signature exactly like the others? It is these degrees of freedom that make an adaptive response and new levels of performance possible. The complexity range of self-organized criticality reflects a (living) system's balance between being complex enough to adapt effectively and minimizing the number of free movements necessary to do so. Unhealthy systems tend to be overly rigid. Overly complex systems and behavioral repertoires tend to waste energy, which could be detrimental in other ways.
More resources for agent-based modeling and related computational programs

On-line Guide for Newcomers to Agent-based Modeling in the Social Sciences Robert Axelrod (University of Michigan) & Leigh Tesfatsion (Iowa State University): The purpose of this on-line guide is to suggest a short list of introductory readings and supporting materials to help readers become acquainted with Agent-based Modeling (ABM).

Sugarscape This is a simulated society developed by the Brookings Institution. It depicts agents interacting in their quest for sugar, and features cellular automata structures. See what happens when they can trade commodities, breed, and spread diseases.

SWARM Agent-based Modeling System -- Sante Fe Institute explains how the SWARM simulation system can be used to describe the self-organizing behavior of heatbugs, moustrap fission, and a small market with one commodity. Contains a portal to advanced materials for SWARM program users.

The Boids by Craig Reynolds. A simulation of a flock of birds developed by Craig Reynolds illustrates how a flock sticks together on the basis of only three rules. Other items on this site show similar properties for a school of fish, and reactions to predators or intruders. More swarms. More videos.

Santa Fe Institute's Complexity Explorer -- Online courses about tools used by scientists in many disciplies.

Evolving Cellular Automata Santa Fe Institute explains cellular automata as computational devices and system simulations for determining the results of self- organizing processes.

Emergence and complexity - Lecture by Robert Sapolsky [video]. He details how a small difference at one place in nature can have a huge effect on a system as time goes on. He calls this idea fractal magnification and applies it to many different systems that exist throughout nature.

 Agent-Based Models One of the problems that made the idea of complexity famous was that if many agents within a system are interacting simul- taneously, it is impossible to calculate the outcomes of each of them individually and predict further outcomes for other agents with which they interact. Calculating the possible orders in which they could possibly interact would be a daunting task by itself. What is possible, however, is to put the agents into a system and allow them to interact according to specific rules. We can also specify different rules for different agents, in which case we have heterogeneous agents. After the simulation has run long enough, the patterns of interaction stabilize into a self-organized system. The figure from Bankes and Lempert (2004) shows distribution of four types of entities that emerged after a period of time in which their agents interacted. Agent-based models are part of a family of computational systems that illustrate self-organization dynamics such as cellular automata, genetic algorithms, and spin-glass models. Briefly, cellular automata are agent-based models that are organized on a grid. One cell affects the action of adjacent cells according to some specified rule. The example shown here is very elementary, but it conveys the core idea. The rule structures are chosen by the researchers within the context of a particular problem. The most extensive work in this area is credited to Stephen Wolfram and his New Kind of Science. Genetic algorithms were first developed to model real genetic and evolutionary processes without having to wait thousands of years to see results. An organism is defined as a string of numbers that represent its genetic code. Organisms then interact in a completely random fashion (or according to other rules specified by the researcher) and "breed." Mutation rules can also be coded into the system. New organisms are then tagged with a fitness index that defines their viability for survival. Ultimately we can see what happens to the computational species relatively soon. Genetic algorithms have also found a home in industrial design. For instance one can take two or more versions of an object, e.g. an automotive design, characterize them as a string of numbers, and let them breed. The results can be filtered for functionality and usability, and aesthetic properties. The winning possibilities might find their way into real-world production. Spin-glass models formed the basis of NK or Rugged Landscape models of self-organizing behavior. In principle some of the agents have common properties, and other agents have different common properties. The properties can be complex and defined and mixed up in any theoretically important way. After a certain amount of "spinning" together in a closed system, they aggregate into relatively homogeneous subgroups. To learn more about agent-based modeling and to see some examples in action, please visit some of the links included here. The Sugarscape model for artificial societies that was developed by economists at the Brookings Institute is particularly comprehensive for its logical development that closely parallels a real-world economy as rules of interaction are sequentially introduced.
 Emergence The common use of the word has proliferated in recent years, but it has a specific, technical origin. Psychologists remember the maxim from Gestalt psychology, "The whole is greater than the sum of its parts." The idea originated in scientific venues a decade earlier, however, with the sociologist Durkheim, who was trying to conceptualize the appropriate topics for a scientific study of sociology. The central concern was that sociology needed to study phenomena that could not be reduced to the psychology of individuals. The essential solution went as follows: The process starts with individuals who interact, do business, and so on. After enough interactions, patterns take hold that become institutionalized or become institutions as we regularly think about them. When the institution forms, it has a top-down effect on the individuals such that any new individuals entering the system naturally conform to the demands, and behavioral patterns, which are hopefully adaptive, of the overarching system. Emergence comes in two forms, light and strong. In the light version, the overarching structure forms but does not have a visible top-down effect. In the strong situations, there is a visible top-down effect. The dynamics of emergence were captured in some laboratory experiments by Karl Weick in the early 1970s on the topic of "experimental cultures." Groups of 3 human subjects were recruited for a group task. They worked together until they mastered their routine. Then, one by one, the members of the groups were replaced by a new person. The replacement continued until all personnel were changed. At the end of 11 generations, the newest groups followed the same work patterns as the original group, even though the originators were no longer part of the system. Two types of emergence are often observed in live social systems. One is the phase shift dynamic. The second is the avalanche dynamic that produces 1/fb relationships. Physical boundaries have an impact on the emergence of phenomena as well. Neuroscientists are also investigating the extent to which bottom- up and top-down dynamics from brain circuits and localization areas are combining to produce what is commonly interpreted as "consciousness."
More Resources for Synchronization

Synchronization of five metronomes [video] -- A reenactment of the phenomenon discovered by Christiaan Huygens which got the whole story of synchronization started. Note: This video automatically links to other excellent examples of Sync.

Interpersonal Synchronization A special issue of NDPLS (April, 2016) examined a fast-moving research area about how body movements, autonomic arousal, and EEGs synchronize between dyads, such as therapy-client dyads, and larger work teams, and the effect synchronization has on various outcomes. See contents. Special order this issue

SyncCalc 1.0 by Anthony F. Peressini & Stephen J. Guastello calculates a coefficient of syn-chronization from several beha-vioral or physiological time series that characterizes the global system. Prototyped for human group dynamics, the algorithm identifies drivers and empaths within the group. Be sure to read the instructions before downloading the program, which is available in PC and MAC formats. The two test data sets are .txt files.

 Synchronization The first example of synchronization in mechanical systems was reported in 1665 by Christiaan Huygens, who noticed that two clocks that were ticking on their own cycles eventually ticked in unison. The communication between clocks occurred because vibrations were transferred between them through a wooden shelf. Another prototype illustration is synchronization of a particular species of fireflies, as told by Steven Strogatz: In the early part of the evening the flies flash on and off, which is their means of communicating with each other, which they do at their own rates. As they start to interact, they pulse on and off in synchrony so that the whole forest lights up and turns off as if one were flipping a light switch. William Strutt opened investigations into the structure of sound waves in 1879, including those that appear synchronized. He observed that two organ pipes generating the same pitch and timbre would negate each other's sound if they were placed too close together. Thus two oscillators could exhibit an inverse synchronization relationship that he called oscillation quelching. Based on the following century of advancements in the study of oscillating phenomena, Pikovsky et al. defined synchronization as "an adjustment of the rhythms of oscillating objects due to their weak interaction" (Synchronization: A universal concept in nonlinear sciences, 2001, p. 8). The oscillators must be independent, however; each one must be able to continue oscillating on its own when the others in the system are absent. Strogatz (Sync: The emerging science of spontaneous order, 2003) concisely described the minimum requirements for synchronization as two coupled oscillators, a feedback loop between them, and a control parameter that speeds up the oscillating process. When the control parameter speeds the oscillating process fast enough, the system exhibits phase lock. Autonomic arousal levels (galvanic skin response) for four emergency response team members working against an attacker (GSR 5). In phase lock, the contributing oscillations all start and end at the same time, with start and end times varying only over a small and rigidly bounded range. If we imagine that the time series of observations produced by a pure oscillator is a sine wave and that its phase-space diagram is a circle, the positions of two or more synchronized oscillators are clustered together as they move around the circle at the same time. Phase synchronization is actually a matter of degree that depends on other matters of degree, such as the tightness or looseness of the coupling produced by the feedback, whether the feedback is unidirectional or bidirectional (or omnidirectional in the case of systems of multiple oscillators), and whether delays in feedback are prominent. The oscillators in a system are not restricted to pure forms; they can be forced, aperiodic, or chaotic processes. In fact, three coupled oscillators are sufficient to produce chaos. This principle has been exploited as a means for decomposing a potentially chaotic time series into its contributing oscillatory components. Chaos can also be controlled by imposing a strong oscillator on the system. Nervous systems are composed of many oscillating and chaotic subassemblies; some activate each other while others are inhibitory. Thus one would anticipate that the products of the nervous system - movements, autonomic arousal, speech and cognition patterns - are also fundamentally chaotic, and that pure oscillators are more often the exception than the rule. The journal Nonlinear Dynamics, Psychology and Life Sciences published a special issue on synchronization (April, 2016) that spanned synchronization within dyadic relationships, relationships that encompassed teams of four or six people, and finally the Nagent case (Sulis). The researchers asked questions such as who synchronizes to whom, in what way, and to what extent? What conditions affect the synchronization of movements, autonomic arousal, speech patterns, and brain waves? Principles of synchronization also lead to some pragmatic questions: How does synchronization promote more successful therapy sessions and more effective work teams? Are there conditions where synchronization is not in the best interest of the dyad or team? If synchronization, which often occurs at a nonverbal level of communication, contributes to desirable decisions and actions at a more explicit level, it can also facilitate negative emotions and irrationality, particularly if stressful conditions are involved.
More Resources for Networks

"An Introduction to Graph Theory and Complex Networks" by Maarten van Steen (2010; 287p., 6MB).

More about network structures and network analysis, by Matthew Denny, Institute for Social Science Research, University of Massachusetts, Amherst. [PDF]

More resources for Applications -- Paradigm & Book Lists

Nonlinear Dynamics, Psychology, and Life Sciences is the refereed research journal of the Society for Chaos Theory in Psychology & Life Sciences. Since its inception in 1997, NDPLS is the only refereed research journal that is uniquely devoted to this range of nonlinear applications and related methodologies. See the journal's home page for contents, data base indexing, citation, editorial, and related information.

This special issue of Nonlinear Dynamics, Psychology, and Life Sciences (January, 2007) was devoted to the paradigm question as it was manifest in a variety of disciplinary areas. See contents. Inquire about availability.

The Impact of Edward Lorenz. Special issue of NDPLS (July, 2009) pays a historical tribute to Lorenz discovery of the butterfly effect, its mathematical history, later developments, and its applications in economics, psychology, ecology, and elsewhere. See contents. Special order this issue.

The Nonlinear Dynamical Bookshelf is a regular feature of the SCTPLS Newsletter (sent to active members) that presents announcements and brief summaries of new books on topics related to nonlinear dynamics. Contents are limited to information we can collect from book publishers or that crawl into our hands by any other means.

Open access book reviews: In an effort to help the world get caught up on its reading, NDPLS has made its book reviews published since 2004 free access on its web site. Browse the journal's contents to see the possibilities.

Books written by members of the Society for Chaos Theory in Psychology & Life Sciences. This list is as complete as we can get it for now, and it is updated regularly. Most are technical in nature. Some of these works go beyond the scope of nonlinear science. Some are whimsical. All are recommended reads.

Recent books by members is a sub-list of the above that lists only those books published with in the past four years.

More resources for Psychology

Chaos and Complexity in Psychology: The Theory of Nonlinear Dynamical Systems edited by Guastello, Koopmans, & Pincus (2009). This collection captures the state of the science of nonlinear psychology in application areas ranging from neuroscience to organizational behavior. For further description and ordering information see Cambridge University Press.

Article: "Chaos as a Psychological Construct: Historical Roots, Principal Findings, and Current Growth Directions" by S. J. Guastello

Chaos, Complexity, and Creative Behavior. Special issue of NDPLS (April, 2011) explores nonlinear dynamics of the cognitive, process, product, and diffusion aspects of creative behavior. See contents. Inquire about availability.

Developmental Psychopathology. Special issue of NDPLS (July, 2012) examines parent-child interactions from a dynamical point of view. See Contents. Inquire about availability.

Article: "Nonlinear Dynamics in Psychology" by S. J. Guastello. This open access article from Discrete Dynamics in Nature and Society, vol. 6, pp. 11-29, 2001 gives an overview of applications in psychology, except neuroscience, as they existed through early 2000.

 Applications - Psychology Psychology has been transforming rapidly with the nonlinear influence. Applications of NDS in psychology include neuroscience; psychophysics, sensation, perception and cognition; motivation and emotion, group dynamics, leadership, and collective intelligence; developmental, abnormal psychology and psychotherapy; and organizational behavior and social networks. The Society's book project, Chaos and Complexity in Psychology: The Theory of Nonlinear Dynamical Systems provides a state-of-the-science compendium (through 2008) of psychological research on the foregoing topics in textbook format. The chapter authors make frequent contrasts between the conventional scientific paradigm and the nonlinear paradigm. The article that follows in the list of links, "Chaos as a Psychological Construct" examines the concept of chaos as it has appeared in a wide range of psychological literature. Uses of the construct range from common use of the word chaos, which usually has no intended reference to formal nonlinear dynamics, to applications where chaos is meant seriously. The research efforts that follow on this page, in psychology and elsewhere, use NDS constructs literally and analytically. The resources list for psychology includes special issues of Nonlinear Dynamics, Psychology, and Life Sciences that are focused on psychomotor coordination and control, creativity, brain connectivity, developmental psychopathology, organizational behavior, and education, and interpersonal synchronization. Other special issues are in the works, and announcements of new projects will appear on our NEWS page and the NDPLS home page. To make matters more interesting, many areas of psychology have embarked on the "biopsychosocial explanation of everything." There is a growing awareness of the interconnections among brain and nervous system activity, cognitive processes and social processes now that we are learning much more about all three realms. The opportunities for new works - and stronger explanations for phenomena - in nonlinear dynamics are extensive. Consider what else is going in the biomedical sciences (next).
More resources for Biomedical Sciences

Optimum Variability. Special issue of NDPLS (October, 2015) examines the relationship system complexity and the health, functionality, and adaptability of biomedical systems, individual well-being, and work group dynamics. See contents. Special order this issue.

Medical Practice. Special issue of NDPLS (October, 2010) offers theoretical and empirical studies that indicate that a paradigm shift in neurology, cardiology, rehabilitation, and other areas of medical practice is very necessary. See contents. Special order this issue.

Brain Dynamics. Special issue of NDPLS (January, 2012) explores developments in brain connectivity and networks as seen through temporal dynamics. See contents. Special order this issue.

Neurodynamics: Special issue of NDPLS in honor of Walter J. Freeman III. Contributing authors extend Freeman’s progressive thinking to new frontiers. See contents. Editorial introduction. Special order this issue.

Psychomotor Coordination and Control. Special issue of NDPLS (Jan. 2009) explores developments in psychomotor learning and skill acquisition and applications to rehabilitation. See contents. Special order this issue.

Handbook on Complexity in Health, edited by J. P. Sturmberg & C. M. Martin (2013) offers over 1000 pages of viewpoints and research on medical thinking and practice, behavioral medicine and psychiatry from the perspective of nonlinear dynamics and complex systems. See table of contents.

 Applications - Biomedical Sciences Some of the first applications in the biomedical sciences explored the comparisons of the fractal dimensions of healthy and unhealthy hearts, lungs, and other organs. Larger dimensions, which indicate greater complexity, were observed for the healthy specimens. This finding gave rise to the concept of a complex adaptive system in other living and social systems. In the area of cognitive neuroscience, memory is now viewed as a distributed process that involves many relatively small groupings of neurons, and that the temporal patterns of neuron firing contain a substantial amount of information about memory storage processing. The temporal dynamics of memory experiments can elucidate how the response to one experimental trial would impact on subsequent responses and provide information on the cue encoding, retrieval, and decision processes. One might examine behavioral response times and rates, the transfer of local electroencephalogram (EEG) field potentials, similar local transfers in functional magnetic resonance images. In light of the complex relationships that must exist in processes that are driven by both bottom-up and top-down dynamics, the meso-level neuronal circuitry has become a new focus of attention from the perspective of nonlinear dynamics. Dynamical diseases, which were first identified by Leon Glass, are those in which the symptoms come and go on an irregular basis. As such, the underlying disorder can be difficult to identify and the symptoms can be difficult to control unless one reframes the problem as one arising from the behavior of a complex adaptive system. This notion has now carried over to the analysis of psychopathologies with some success. There are, in turn, further implications for medical practice, David Katerndahl and other writers have observed that the mainstay of medical practice in most countries still revolves around the single cause mentality. Research Example 4: A sample EMG time series and corresponding recurrence plot for one participant during a single experimental trial of a vertical jump task. From Kiefer, A. W., & Myer, G. D. (2015). Training the antifragile athlete: A preliminary analysis of neuromuscular training effects on muscle activation dynamics. NDPLS, 19(4), 489-510. Research Example 5: The shape of the T cells nuclei (transmission electron microscopy of the skin, x 15000) is more complex in the tumor (right) in comparison to flogosis (chronic dermatitis, left). From Bianciardi, G. (2015). Differential diagnosis: Shape and function, fractal tools in the pathology lab. NDPLS, 19(4), 437-464.
More resources for Organizational Behavior

Nonlinear Organizational Dynamics. Special issue of NDPLS (January, 2013) presents empirical studies on individual work performance, group dynamics, organizational behavior. See Contents. Special order this issue.

Article: "A Complex Adaptive Systems Model of Organizational Change," by K. J. Dooley.

Article: "Nonlinear dynamical systems for theory and research in ergonomics," by S. J. Guastello. Ergonomics, 2017, 60, 167-193. Request reprint from author.

Advanced Modeling Methods for Studying Individual Differences and Dynamics in Organizations. In this special issue of NDPLS, authors consider the possible uses of growth curve modeling, agent-based modeling, cluster analysis, and other techniques to explore nonlinear dynamics in organizations. See Contents. Editorial introduction. Special order this issue.

More resources for Economics & Policy

Complexity in economics edited by J. B. Rosser, Jr. The international library of critical writings in economics 174. UK: Edward Elgar. This 3-volume set (2004) compiles a wide range of important and fundamental works on nonlinear dynamics in all the areas of economics. Further description and ordering information.

Article: "Complexity and Behavioral Economics" by J. B. Rosser, Jr. & M. V. Rosser (2015). The works of H. Simon figure prominently in this survey-review article.

 Applications - Ecology Ecological applications of NDS fall into the domains of both biologists and economists. Topics of nonlinear interest most often include population dynamics, prey-predator dynamics, the complex web of relationships among co-dependent species, and the impact of human interventions such as fish and livestock harvesting and agriculture generally. The logistic map function, which was described above as a classic bifurcation structure, originated with population studies, and has in turn inspired numerous studies outside of ecology that involve transitions between chaotic and non-chaotic temporal patterns. Robert May is credited for landmark modeling strategies for ecological systems that involve birth rates, environmental carrying capacity, and other intervening factors. Research Example 10: The human population of Easter Island is graphed for f (decrease in the growth rate of trees) ranging from .0004 to .001. For small values of f the population oscillates around the coexistence equilibrium, and for larger values of f the human population is unstable and crashes. These diagrams illustrate that the stability of the coexistence equilibrium in the Invasive Species Model is sensitive to the parameter modeling the effect of the rats on the island's ecosystem. From Baesner, W. et al. (2008). Rat instigated human population collapse on Easter Island. NDPLS, 12(3), 227-240. Research Example 11: Dependence of the averaged plant biomass as a function of insect production rates; O = oscillations, * = chaos. Simulation parameters roughly correspond to the length of a normal growing season. From Medvinsky, A. (2009). Chaos and predictability in population dynamics. NDPLS, 13(3), 311-326.

Nonlinear Dynamics in Education. Special issue of NDPLS (January, 2014) examines parent-child interactions from a dynamical point of view. See Contents. Special order this issue.

 Applications - Education Applications in education cover a range of individual-level, group-level, and institutional level topics. Examples include student learning and motivation dynamics, social dynamics in the classroom or school, student-teacher interactions, career development, absenteeism, and the long-run effect of policy concepts on the success of metropolitan school systems. There is some parallel between the topics addressed as education issues and those in organizational behavior more generally. Research Example 12: A state space describing the dimensions 'help given by the teacher' and 'number of math problems solved during one lesson by the student,' together forming a dynamic system. During the first lesson the student is given much help and solves only a few problems. Eventually the system settles into an attractor state. From Steenbeek, H., & van Geert, P. (2013). The emergence of learningteaching trajectories in education: A complex dynamic systems approach. NDPLS, 17(2), 233-268.
More Resources for Nonlinear Methods

Nonlinear Dynamical Systems Analysis for the Behavioral Sciences Using Real Data, edited by Stephen J. Guastello and Robert A. M. Gregson (2011). Book covers a wide range of traditional and statistically based techniques for nonlinear analysis, examples, experimental design tips, and software operation. See description.

Tutorials in Contemporary Nonlinear Methods for the Behavioral Sciences, edited by M. A. Riley & G. C. Van Orden (2005). A Digital Publication.

TISEAN Nonlinear Time Series Analysis Routines by H. Kanz & T. Schreiber. This widely used program computes correlation dimensions and other traditional metrics from real data after applying a nonlinear filering routime for error variance. Free donwload, written in C).

Time Series Data Sources. We put together a list of resources where you can time freely available time series data in economics, physiology, etc.

 An Overview of Nonlinear Methods This section is compiled for the benefit of researchers who are considering how they might start a project and organize their data analysis. The first step is to conceptualize the formal dynamics that could apply to a problem and build a substantive theory in which psychological or other qualitative variables contribute to the dynamics. The model should be testable. Analytic strategies that have been developed to make computations that inform about the dynamics occurring in a data set include: the fractal dimension, Hurst exponent, Lyapunov exponent, BDS statistic, several measures of entropy, analyses based on polynomial regression or nonlinear regression, Markov chains, and symbolic dynamics. There are also visualization techniques such as phase space analysis, state-space grids, and recursion plots that have means for quantifying dynamics and various properties of the time series. A strong theory about the phenomenon would greatly reduce the number of models that should be tested. By the same token, there is no reason to believe that the theoretical models that originated in mathematics would be observed in their idyllic forms in real data. Noise is always a challenge. For instance, there were some early disappointments when what was thought to be chaos turned out to be noise generated by the laboratory equipment. One remedy for noise is to filter the data first, then proceed with the calculations of choice results. By 'direct calculations' we mean some computations that researchers have found meaningful early on were not statistical in nature, meaning that they assumed no further error in the data, did not rely on probability functions, and did not provide inferential tests of hypotheses. Statistical procedures for capturing the same underlying constructs were soon introduced. The strategy is that a nonlinear model, chaotic or otherwise, needs to be tested statistically and separated from residual variance. Filtering is sometimes possible as when laboratory is corrected for AC hum. Noise can be introduced, however, from all sorts of uncontrolled sources - uncontrolled events in the laboratory experiments, uncontrolled individual differences in responses to the experimental conditions, and measurement error. In the classical measurement theory that social scientists usually rely upon, the measurement error (or noise) in a static distribution of observations is independent of any other errors and independent of the underlying true score or measurement. When the measurement is observed over time, however, the error subdivides into the classic form of error, which is now called independently and identically distributed (IID) error, and dependent error. Dependent errors interact with the true scores and other errors over time. The presence of dependent error is one hallmark of a nonlinear function. The researcher then employs a statistical analyses, such as polynomial regression or nonlinear regression, evaluate the degree of fit between the model and data. The remaining variance unaccounted for is error, although it might offer some clues regarding how a modified model could be better. Note that there is an assumption here that noise and 'true measurements' are inseparable in raw form, and the goal of the analysis is to separate the two portions of variance. Transient effects are complications that occur in the dynamics themselves. When transient effects occur, the dynamics change for a period of time, and sometimes revert to the original dynamic pattern. Transients can be difficult to identify and separate from the core dynamic if the data sets are relatively short, which they often are. The advisement to researchers is to look for a rule by which the dynamics switch from one model to another, or from the core dynamic to a [generic] transient and back again. That said, we can provide an overview of the analyses that have had the largest impact. The analyses can be divided between traditional deterministically-based procedures. The traditional methods include phase space analysis, the correlation dimension, and the Lyapunov exponent. The stochastically-based procedures, which are often more compatible with problems in the social sciences, include statistical analysis for catastrophe models, redefinitions of the Lyapunov exponent and correlation dimension for statistical analysis, some advanced strategies for phase space analysis, and Markov Chain analysis. Recursion Quantification Analysis (RQA), state space grids, symbolic dynamics techniques, and entropy statistics fall somewhere between the two camps.
 Phase Space Analysis A phase space diagram is a picture of a dynamical process that can tell us quite a bit about the behavior of a system that follows a particular function. It is usually drawn as a plot of the change in X (DX) at time t+1 as a function of X at time t - velocity versus position. The figures shown earlier for the fixed point, limit cycle, and Lorenz attractors are phase space diagrams. There are a couple other varieties of phase space diagram such as the return map, which is a plot of X at time t+1 (rather than DX) as a function of X at time t, and plots of two variables that are part of a more complex function that involves two order parameters. Phase space diagrams are useful tools for visualizing the dynamics inherent in a data set. They are usually supplemented with metrics such as the correlation dimension or Lyapunov exponent. It can be challenging to produce phase space diagrams for real data because they do not provide any inferential statistics by themselves, and the appearance of the diagram can be seriously affected by noise and by projecting the time series in an inadequate number of spatial dimensions. Problems of spatial projection are generally handled through analyses such as false nearest neighbors or principal components analysis. Phase space diagrams for two chaotic attractors: The Henon-Hiles (upper), and the Rossler (lower). Color is often used to capture a fourth dimension of the attractor.
Correlation Dimension

Three descriptive metrics that are commonly applied to a time series are the correlation dimension, the Lyapunov exponent, and the Hurst exponent. The correlation dimension is a computation of a fractal dimension. The basis of the algorithm is to take the time series, treat it as a complicated line graph, and cover the graph with circles of radius r. It then counts the number of circles required, then changes the radius and repeats many times. Then it correlates the log of the number of circles required with the log of the radius. The result will be a line with a negative slope. The absolute value of the slope is the fractal dimension.

Another popular calculation, involves the use of an embedding dimension, which is described in the section on fractals appearing earlier. The correlation dimension is computed first with the assumption of an embedding dimension of 1, then assuming 2 dimensions, then 3, and so on. The computed fractal dimension will increase along with the embedding dimension up to a point where it reaching an asymptote, which is the final answer. The Grassberger-Procaccia algorithm is usually used for this purpose and is included in the TISEAN and other software packages. The fractal dimension can also be rendered by statistical means, which are described in a later section of this page.

As mentioned earlier (and see the various links), fractal dimensions characterize many structures of living and physical systems. They are fractional taking on values in between the integer values associated with elementary geometry. Table 1 contains some rough interpretations.

Interpretation of Correlation Dimensions

ValueInterpretation
Near 0 Denotes a fixed point
1.0 A line or an open circle
1.0 - 2.0 A chaotic system that has self-organized into a lowdimensional configuration (self-organized criticality). This range is also known as 'pink noise.'
2.0 Points are evenly distributed around a two-dimensional surface. This is Brownian motion in 2-D. Beware: Some rather famous chaotic attractors have dimensions that are very close to 2.0.
2.0 - 3.0 Motion is relatively small and steady but punctuated with large bursts. Or, we have a physical landscape that relatively flat, i.e., closer to 2.0, or relatively rugged, closer to 3.0. Many chaotic attractors have dimensions in this range.
3.0 Brownian motion in 3-D. All 'molecules' are bouncing around and reaching every possible location in the container.
> 3.0 Chaos is likely in a time series. Beware: (a) The correlation dimension is not an effective test for chaos. (b) Not all chaos occurs in a chaotic attractor.
Very Large Data probably consist of white noise, where virtually every point follows its own path, unconnected to the trajectories formed by the other points.
 Surrogate Data Analysis and Experiments The presence of fractal structure, if it is calculated through a non-statistical method, is usually contrasted against an alternative interpretation, which is that the fractal value for the time series could occur by chance. A statistical test of this proposition can be performed as follows: (a) Take the time series and randomly shuffle all the points. This process will preserve the overall mean and standard deviation of the time series, but will disrupt any serial dependency among the points if it exists. (b) Repeat the shuffle 10, 100, 1000 times. (c) Calculate a fractal dimension on each of the shuffled time series, and calculate the mean and standard deviation of each of the fractal dimensions that are obtained. (d) What are the odds that the fractal dimension that was obtained from a true nonlinear function and not from the distribution of values obtained from the shuffled time series? Another way to finesse the noise problem is to conduct an experiment in which something that is thought to affect the complexity of the time series is systematically varied. In an experiment, one might have separate groups of human subjects that are performing a task under different conditions, and each subject is producing a time series. Calculate the correlation dimension for each subject, then compare the groups using a t-test, analysis of variance, or similar type of analysis for an experiment. Non-parametric statistics are often preferred, however. Any distortions in the nonlinear metric that were caused by error, noise, or sampling are assumed to be equal or varying randomly across the experimental conditions, and the mean differences in metrics such as the fractal dimension, entropy, etc. are what matter.
 Lyapunov Exponent The Lyapunov exponent evaluates the relative amount of expansion and contraction between successive pairs of points in a time series. It is perhaps best interpreted as a measure of turbulence in a physical process or time series data. As mentioned previously, it is actually a spectrum of values (when calculated through the direct, or nonstatistical method). If the largest value is a positive number, the series is chaotic. If the largest value is negative, the series is contracting to a fixed point. Values of 0 indicate either a straight line or a perfect oscillator. The nonstatistical algorithms for the Lyapunov exponent are also susceptible to distortions induced by noise. Once again surrogate data analysis or statistically-based procedures can alleviate this problem. The largest Lyapunov exponent, , once obtained, can be converted to a fractal dimension via the Kaplan-Yorke Conjecture: DL = e. Fractal dimensions (DL) calculated in this fashion should more precisely identified as Lyapunov dimensions to distinguish the algorithm used to produce it. Turbulent air flow. Produced and photographed by Candace Wark and Shirley Nannini. For more information, see their article 'Cover images: Flow visualization,' NDPLS, 21(1), 113-116.
 The Hurst Exponent The Hurst exponent, H, was first devised as a means of determining the stability of water levels in the Nile River. Water flows in and flows out, but is the net water level relatively stable or does it oscillate? To answer this question, a time series variable, X with T observations is broken into several subseries of length n; n is arbitrary. Then for each subseries, the grand mean is subtracted from X, and the differences summed. The range, R, is the difference between the maximum and minimum values of the local means. Then rescaled range, R/s = (*n/ 2)H, where s is the standard deviation of the entire series; 0 < H < 1. Actual values of H may vary somewhat due to the choice of n and the time scale represented by the individual observations. A value of H = 0.5 represents Brownian motion, meaning that the deflections in a time series can be upward or downward with equal probability on each step. Brownian motion has a Gaussian distribution and is non-stationary. Values that diverge from 0.5 in either direction are non-Markovian, meaning that there is memory in the system beyond the first step prior to an observation. H > 0.5 denotes persistence. Deflections in a time series gravitate toward a fixed point if H is high enough. The autocorrelation of observations in a time series is positive. Values in the neighborhood of 0.75 represent pink noise or self-organizing systems. H < 0.5 denotes anti-persistence; upward motions are followed by downward motions, and the autocorrelation is negative. In spite of the official range of H lying between 0 and 1, negative values have been recently reported. The negative values arose from the presence of a bifurcation in the data. It does not follow, however, that all instances of bifurcations, such as those found in catastrophe models, will always produce negative H values for a time series. Further research is required on this matter. Research Example 13: This time series for a cognitive task, which was performed under conditions of fatigue, displayed a negative Hurst exponent. From: Guastello, S. J., Reiter, K., Shircel, A., Timm, P., Malon, M., & Fabisch, M. (2014). The performance-variability paradox, financial decision making, and the curious case of negative Hurst exponents. NDPLS, 18, 297-328.
 State Space Grids The state space grid is a technique and computational program developed by Tom Hollenstein for identifying attractor structures in experiments with real data. As such, it is a useful alternative to the phase diagram when it is not possible to deploy algorithms that involve multidimensional projections of data. The application starts with two variables that consist of ordered categories. For instance, mother might behave in any of several ways, and the child have any of several responses. Each observation consists of a point that denotes the mother-child combination. The algorithm connects the dots in time series. The algorithm then identifies the cells that are most dense and can be interpreted as attractors. One can then conduct experiments comparing theoretically interesting conditions and make statistical associations between the number and type of attractors in the study. Research Example 14: An example of a state space grid depicting a highentropy and high conflict relationship, from Dishion, T. J., Forgatch, M., Van Ryzin, M., & Winter, C. (2012). Nonlinear dynamics of family problem solving in adolescence: The predictive validity of a peacheful resolution attractor. NDPLS, 16(3), 331-352.
More resources for Recurrance and Cross-Recurrance Quantification Analysis, comprehensive site incl. software links.
 Recurrence Plots and Analysis Although chaotic functions are said to produce non-repeating patterns, repeatability is really a matter of degree. Visualizing what repeats and how often can provide new insights to dynamics of a process. A recurrence plot starts with a time series. The user specifies a radius of values that are considered to be similar enough and a time lag between observations that should be plotted. If a the same value of X(t) appears after one or more lag units, a point in plotted. The variable itself appears on the diagonal. White noise would produce a plot containing a relatively solid array of dots with no patterning. An oscillator would produce diagonal stripes. More interesting deterministic functions would produce patterns; an example pattern appears at the right. One can then calculate metrics that distinguish one pattern from another such as the percentage of total recurrences arising from the deterministic process, percentage of consecutive recurrences, and the maximum length of the longest diagonal (shorter is more chaotic). Recurrence plots were first introduced as a procedure to accompany phase space analysis. New metrics, such as percent determinism, were eventually introduced, and the name of the technique morphed into recurrence quantification analysis (RQA). The new metrics were valuable for interpreting a time series. Importantly RQA analysis does not need to be accompanied by phase space analysis or assumptions about embedding versus fractal dimensions for proper interpretation. A variation on the concept is to use plots of data from two different sources (people) on the two axes instead of one source at two points in time. This cross-recurrence technique has been used as one method for studying synchronization phenomena. Research Example 15: Recurrence plot for real (left) and reshuffled (right) data. From Sabelli, H. (2001). Novelty, a measure of creative organization in natural and mathematical time series. NDPLS, 5(2), 89-114.

Nonlinear Dynamics in SPSS. Contains instructions for analyzing real data for hypotheses concerning catastrophe models, Lyapunov exponents and chaos, bifurcation effects, and attractor structures using subprograms in the Statistical Package for the Social Sciences (SPSS) for polynomial regression and nonlinear regression.

 Nonlinear Statistical Theory There is another genre of analysis that starts with a relatively firm hypothesis that a particular nonlinear function is inherent in the data. The function could be chaotic or reflect other types of dynamics. In the particular case of chaotic data, the objective is to separate chaos from noise, just as one would separate a linear trend from noise in a conventional regression analysis. Consistent with four goals of inferential statistics, the regression-based analyses can predict points, identify the nonlinear dynamics in the data, report a measure of effect size, and determine statistical significance of the parts of the respective models. The next subsections of this exposition address issues concerning probability density functions, the structure of behavioral measurements, stationarity of time series, and what can be done to serve the ultimate objectives. Students of the late 20th century behavioral sciences were taught to divide their probability distributions into four categories: normal (Gaussian) distributions, those that would be normal when the sample sizes became larger, those that would be normal if transformations were employed, and those that were so aberrant that non-parametric statistics were the only cure. In the NDS paradigm, however, one is encouraged to assume specific alternative distributions such as power law, exponential, and complex exponential distributions. To take things a step further, any differential function can be rendered as a unique distribution in the exponential family, and the presence of an exponential distributions or a power law distribution in a time series variable denotes a nonlinear function contained therein. Dependent error in a dynamical process, which was introduced earlier, might occur like this: Imagine we have a measurement that is iterating through a process such that X2 = f(X1). The function produces X3, X4, etc. the same way. Now let a random shock of some sort intrude at X4. At the moment the shock arrives, the error is IID. At the next iteration, however, X5 = f(X4 + e); the error continues to iterate with the true score through the ensuing time series. Other ways for dependent error to occur are when errors are autocorrelated or when complex lag effects are in play such that X(t) = f[X(t-1), X(t-3)]. Fortunately there is a proof due to William Brock and colleagues showing that the presence of dependent error in the residuals of a linear autocorrelation is a positive indicator of nonlinearity. Furthermore, if a good-enough nonlinear function is specified for the true score, the dependent error is reduced to a minimum. So, what does it take to specify a good-enough nonlinear function? Researchers should have the dynamics for their theory worked out in sufficient detail. To do so requires study of the extant literature on the particular application. Fortunately there are some groups of options that have some degrees of flexibility. Consider two examples: Example 1: z = b0 + b1z13 + b2Bz1 + b3A Example 2: z2 = 1Bz1*exp(2z1) + 3 where z is the dependent variable (order parameter) that is measured at two or more points in time, z is a change in the dependent variable, A and B are control (independent) variables, bi are linear regression weights, and i are nonlinear regression weights. For models similar to Examples 1 and 2, data are prepared by setting a zero point and a standard calibration of scale for all variables in the model. Thus the dependent variable is represented by z instead of the conventional X or Y. Any error associated with approximating a differential function from a difference function becomes part of [1- R2]. The use of R2 in this context is predicated on the use of least squares statistical analysis, which is an effective and very reasonable approach to nonlinear statistical analysis. Example 1 is a cusp catastrophe executed with ordinary polynomial regression. Example 2 is part of a series of exponential models developed by Stephen Guastello that is executed through nonlinear regression. In Example 2, 2 corresponds to the largest Lyapunov exponent; if 2 is positive and 3, the constant, is negative, then both expanding and contracting properties exist in the data set. Expanding and contracting trajectories denote chaos. It is also possible to expand the model by substituting a second exponential function for 3. There is also a series of model structures for determining oscillators and coupled oscillators that was developed by Steven Boker, Jonathan Butner and colleagues; the essential concepts of nonlinear time series analysis apply to these structures as well. The results of the nonlinear models should be compared against alternative theoretical models. The researcher is looking for a higher degree of fit between the model and the data compared to the alternatives, and all the parts of the nonlinear model should be supported as well. The alternatives are often linear but not always so.
 Maximum Likelihood Methods Jonathan Butner and colleagues have been experimenting with new adaptations of growth mixture modeling, multilevel modeling, and latent class analyses for identifying dynamics in data. The essential problem that they are addressing is that one might have no clue (hypothesis) in advance as to what combinations of attractors, bifurcations, or saddles, might be lurking in the data. The first two diagrams at the right are time series plots of two variables in a system they were studying. The third is a vector and density plot of the two variables. Research Example 16: Time series for two system variables (upper), and a vector-and-density plot of the two variables (lower). From Wiltshire, T. J., Butner, J. E., & Pirtle, Z. (2017). Modeling change in project duraction and completion: scheduling dyanmics of NASA's Exploration Flight Test 1 (EFT-1) activities. NDPLS, 21(3), 335-358.
 Markov Chains The concept of Markov chains originated outside the realm of nonlinear science. The central idea is that the researcher is observing objects or people in a finite set of possible states. Objects all have odds of moving from one state to another. The State X State matrix of odds is a transition matrix. The analysis establishes the transition matrices and determines the arrival of objects into states. Stephen Merrill illustrated that some combinations of transitions could result in fixed points, oscillators, bifurcations, or chaotic outcomes. Thus Markov chain analysis now falls into the scope of nonlinear dynamical analyses. There is also a subtle connection between Markov chain analyses and the methods of symbolic dynamics that have been deployed for real data in the behavioral sciences thus far.

Orbital Decomposition v2.4 by Anthony F. Peressini & Stephen J. Guastello. A symbolic dynamics routine for determining patterns in nominally coded (categorical states) time series data. The standard routine computes pattern length and optimal solutions; topological, Shannon and Kolmogorov- Sinai entropy, Lyapunov dimensions, and statistics for goodness of fit. Version 2.4 now allows you to decipher patterns from multiple categorical variables.

Be sure to read the instructions before downloading the program, which is available in PC and MAC formats. The three test data sets are .txt files: data1, evendemo, ragdemo.

 Symbolic Dynamics Symbolic dynamics is an area of mathematics that finds patterns in series of qualitative data. The elementary patterns themselves can be treated like qualitative states and analyzed for higher order patterns. This class of techniques is ideally suited to analyzing chaotic and related complex nonlinear dynamics, either in the form of continuously valued time series or qualitative categorical data. Symbolic dynamics are particularity useful in situations in which discontinuities, continuities, periodic functions, and unnamable transients could co-exist within a relatively short time series. For continuous data, events such as spikes and small or large up-trends and down-trends are coded nominally (e.g., with letter codes A, B, C, D, etc.) and then analyzed. For categorical data, the categories, which should be theoretically relevant, are also given letter codes, and the computations are carried out essentially the same way. The techniques that are available vary in their means for determining symbol sequences and the length of those sequences. Orbital Decomposition (ORBDE) analysis, which was developed by Stephen Guastello and colleagues, can disentangle periodic patterns that contribute to a globally chaotic time series. It is particularly good for empirically determining the optimal pattern length. It includes entropy metrics and tests for determining the extent to which the patterns that were isolated by the analysis deviate from chance levels of occurrence. In this way it can distinguish between chaotic and random sequences. Topological entropy is the primary entropy metric used for determining pattern length. It approximates the Lyapunov exponent under limiting conditions. Unlike Shannon entropy, which is also reported in the analysis, the topological entropy metric preserves the temporal sequence of the events that are being extracted. The ORBDE software is available from the link at the left. The current version (2.4) allows analysis for multiple categorical variables to be evaluated simultaneously. One can also apply varying numbers of codes to a single event. For instance, a short utterance in a conversation between two or more people might have only one category of content (e.g. asking a question), but a longer utterance might contain several categories of content. Komolgorov-Sinai entropy, which is an expansion of Shannon entropy, is calculated for the multiple-variable analyses.
